Engine
- Engine type
- Liquid-cooled, 4-stroke Single
- Compression ratio
- 13.4:1
- Valve system
- DOHC, 4 valves
- Bore x stroke
- 77.0 x 53.6 mm
- Displacement
- 249 cm�
- Fuel system
- Fuel injection: 43 mm x 1 (Keihin) with dual injection
- Ignition
- Digital DC-CDI
- Starting System
- Primary Kick
- Lubrication
- Forced lubrication, semi?dry sump
Performance & Transmission
- Transmission
- 5-speed, return
- Clutch
- Wet multi-disc, manual
- Primary Reduction Ratio
- 3.350 (67/20)
- Gear Ratios 1st
- 2.142 (30/14)
- Gear Ratios 2nd
- 1.750 (28/16)
- Gear Ratios 3rd
- 1.444 (26/18)
- Gear Ratios 4th
- 1.235 (21/17)
- Gear Ratios 5th
- 1.045 (23/22)
- Final Reduction Ratio
- 3.846 (50/13)
- Final drive
- Chain
Brakes & Suspension
- Brakes, front
- Single semi-floating 270 mm petal disc. Caliper: Dual-piston
- Brakes, rear
- Single 240 mm petal disc. Caliper: Single-piston
- Suspension, front
- 48 mm inverted telescopic Separate Function front Fork (SFF) Type 2. Compression damping: 22-way. Rebound damping: 20-way. Spring preload: 40-way
- Suspension, rear
- Uni-Trak. Compression damping: 19-way (low-speed), 4-turns (high-speed). Rebound damping: 22-way. Spring preload: Fully adjustable
Frame & Dimensions
- Frame type
- Perimeter, aluminium
- Trail
- 123 mm
- Wheel travel front
- 310 mm
- Wheel travel rear
- 310 mm
- Tyre, front
- 80/100-21 51M
- Tyre, rear
- 100/90-19 57M
- Steering angle L/R
- 42° / 42°
- L x W x H
- 2,172 x 825 x 1,270 mm
- Wheelbase
- 1,478 mm
- Ground clearance
- 324 mm
- Fuel capacity
- 6.4 litres
- Seat height
- 945 mm
- Curb mass
- 104.7 kg
